Armor 500T Plates
MILITARY, ARMOR & BALLISTIC STEEL PLATE : High hardness armor with extraordinary toughness properties
Armor® 500/500T is the world's toughest protection plate, having nominal 500 HBW hardness, for use in vehicles, buildings and many more applications.
Benefits of Armor 500/ 500T Include
• Market-leading steel protection
• Superior workshop properties
• Optimized solutions
• Perfect hardness/toughness balance, for combined penetration and blast protection
• Expertise in ballistic protection from SSAB
It offers vehicle designers new ways to increase protection using lighter weight designs. Armor 500T is not intended for further heat treatment.
• Superior workshop properties
• Optimized solutions
• Perfect hardness/toughness balance, for combined penetration and blast protection
• Expertise in ballistic protection from SSAB
It offers vehicle designers new ways to increase protection using lighter weight designs. Armor 500T is not intended for further heat treatment.
Armor 500T
| USED FOR | DIMENSIONS | STANDARDS |
| Armored | T: 3 - 80 mm | EN 10029 |
Mechanical Properties
| Thickness(mm) | Hardness(HBW) | Charpy-V1), 10x10 mm test specimen2)Min. | Yield Strength Rp0.2(min MPa) | Tensile Strength Rm(MPa) | Elongation A5(min %) | Elongation A50(min %) |
| 3.0 - 80.0 | 480 - 540 | 32 J / -400C | 1250 | 1450 - 1750 | 8 | 10 |
Chemical Composition (ladle analysis)
| C *)(max %) | Si *)(max %) | Mn *)(max %) | P(max %) | S(max %) | Cr 1)(max %) | Ni 1)(max %) | Mo *)(max %) | B *)(max %) |
| 0.32 | 0.4 | 1.2 | 0.01 | 0.003 | 1 | 1.8 | 0.7 | 0.005 |
Tolerances
| Thickness(mm) | Tolerances(mm) |
| 3.0 - 12.9 | - 0.0 / + 0.6 |
| 13.0 - 20.0 | - 0.0 / + 0.8 |
| 20.1 - 40.0 | - 0.0 / + 1.0 |
| 40.0 - 59.9 | - 0.0 / + 1.4 |
| 60.0 - 80.0 | - 0.0 / + 1.6 |
