Armor 500 Plates
MILITARY, ARMOR & BALLISTIC STEEL PLATE: The ballistic protection steel with high hardness
Armor™ 500 is a ballistic protection steel of high hardness, available in thicknesses of 2 30 mm (0.079 1.18″) and hardnesses of 490 560 HBW.
Armor 500 is available as cut-to-length sheet in thicknesses of 2 6.5 mm (0.079 0.256″) and as plate in thicknesses of 6 30 mm (0.236 1.18″). Delivered in quenched condition, Armor 500 is not intended for further heat treatment.
Armor 500 is available as cut-to-length sheet in thicknesses of 2 6.5 mm (0.079 0.256″) and as plate in thicknesses of 6 30 mm (0.236 1.18″). Delivered in quenched condition, Armor 500 is not intended for further heat treatment.
Armor 500
| USED FOR | DIMENSIONS | STANDARDS |
| Armored | T: 2 - 30 mm | EN 10029, EN 10051 |
Mechanical Properties
| Thickness(mm) | Hardness(HBW) |
| 2.0 - 30 | 490 - 560 |
Chemical Composition (ladle analysis)
| C (max %) | Si (max %) | Mn (max %) | P(max %) | S(max %) | Cr (max %) | Ni (max %) | Mo (max %) | B (max %) |
| 0.35 | 0.70 | 1.50 | 0.015 | 0.010 | 1.0 | 2.0 | 0.70 | 0.005 |
Tolerances
Thickness
| Product Type | Thickness(mm) | Tolerance (Min / Max) |
| Cut Length | 2.00 - 4.00 | - 0.0 / + 0.36 |
| Cut Length | 4.01 - 5.00 | - 0.0 / + 0.40 |
| Cut Length | 5.01 - 6.00 | - 0.0 / + 0.42 |
| Cut Length | 6.01 - 6.50 | - 0.0 / + 0.44 |
| Heavy Plate | 6.0 - 7.9 | - 0.0 / + 0.8 |
| Heavy Plate | 8.0 - 14.9 | - 0.0 / + 1.0 |
| Heavy Plate | 15.0 - 24.9 | - 0.0 / + 1.2 |
| Heavy Plate | 25.5 - 30.0 | - 0.0 / + 1.4 |
Flatness
| Product Type | Thickness(mm) | 1000 ruler(mm) |
| Cut Length | 2.00 - 4.00 | 6 |
| Cut Length | 4.01 - 5.00 | 6 |
| Cut Length | 5.01 - 6.00 | 6 |
| Cut Length | 6.01 - 6.50 | 6 |
| Heavy Plate | 6.0 - 7.9 | 6 |
| Heavy Plate | 8.0 - 14.9 | 6 |
| Heavy Plate | 15.0 - 24.9 | 6 |
| Heavy Plate | 25.5 - 30.0 | 6 |
