the leading stockiest, importers, exporters & suppliers of Alloy 330 Plates

Alloy 330 Plates


Champak Industries stockiest, supplier, importer, and exporters of Alloy 330 Plates or nickel alloy plate in thicknesses from 3/16" (4.8mm) through 1" (25.4mm) for applications in the chemical and petrochemical, Thermal also in the power generation industry. Alloy 330 (UNS N08330) is comparable to and competes directly with Rolled alloy 330.

Available thicknesses for Alloy 330 plates

3/16" 1/4" 3/8" 1/2" 5/8" 3/4" 1"
4.8mm 6.3mm 9.5mm 12.7mm 15.9mm 19mm 25.4mm
Alloy 330 (USN08330) is an austenitic nickel-iron-chromium alloy evolved to offer first-rate resistance to carburizing and oxidizing atmospheres at elevated temperatures. With a nickel content of 34 to 37 percentages, the alloy stays fantastically proof against each chloride pressure corrosion cracking and embrittlement from the precipitation of sigma phase. It's far effortlessly fabricated using fashionable strategies for stainless-steel and nickel alloys. The alloy is used substantially in extended temperatures where resistance to the blended consequences of thermal biking and carburization is needed.

Applications

 Chemical and Petrochemical Processing
o Cracked ammonia components
o Petrochemical furnace parts
o Petrochemical waste remediation units
o Heat exchangers
o Flares

 Ore Processing
o Perlite systems and equipment

 Power Generation
o Boiler fixtures
o Gas turbine components

 Thermal Processing
o Heat-treat furnace containers
o Heat-treat furnace components
o High temperature fans
o Salt pots

Applications

ASTM..................B 536
ASME..................SB 536
AMS...................5592

Chemical Analysis

Typical Values (Weight %)

Nickel 34.0 - 37.0 Chromium 17.0 - 20.0
Iron Balance* Carbon 0.08 max.
Silicon 0.75 - 1.50 Manganese 2.0 max.
Phosphorus 0.030 max. Sulfur 0.030 max.
Thermal and Electrical Properties

Temperature Thermal Conductivity Electrical Resistivity
°F °C Btu-in/ft2M/-h-°F W/m-°C ohm-circ mil/ft mW-m
75 24 86 12.4 612 1.017
400 204 108 15.6 649 1.079
800 227 134 19.3 688 1.144
1200 649 162 23.4 721 1.199
1600 871 198 28.6 744 1.237
1800 982 216 31.2 749 1.245

Mechanical Properties

Typical Room Temperature Mechanical Properties, Mill Annealed

Yield Strength
0.2% Offset
Ultimate Tensile
Strength
Elongation
in 2 inches (50mm)
Hardness
ksi (MPa) ksi (MPa) % Rockwell B
30 - 43 207 - 296 80 - 85 552 - 586 40 - 45 70 – 85
