Champak Industry - steel plate manufacturers, boiler quality steel plates, structural steel plates supplier, ship buildings steel plates, stainless steel plate suppliers, stainless steel sheets manufacturer, steel products manufacturers, stainless steel products supplier, industrial steel plates manufacturer, alloy steel plate suppliers. Available with us, is a sturdy assortment of abrasion resistant steel, corten steel & plates that is highly acclaimed by our global clients due to its durability and similar other attributes. Designed from high grade stainless steel and other alloys, these plates are offered to our clients in standard and customized specifications. These plates are offered in different types like boiler quality plates, corten steel products, structural steel plates, abrasion resistant steel plates, alloy sheet plates, ship building steel and quenched & tempered steel plates.

Steel Plate Manufacturers,Boiler Quality Steel Plates

Boiler Quality Plates

We are instrumental in manufacturing and exporting an industrially verified range of boiler quality plates that is used for industrial and commercial purposes. These sturdy boiler quality plates are designed to be at par with the industrial quality standards and are obtainable for our clients in customized forms. Specifications:

Specification	Chemical						Mechanical MPA, min
Specification	C Max	Min Max	Si Max	S Max	P Max	CE	Tensile Min	Yield Min	% EL 50 GL	Min 200 GL	Bend	Impact
ASTM-A 515 Gr - 60 Gr - 70
	0.22	0.90	0.15 0.40	0.035	0.035	---	415 550	220	25	21	1.5T	---
	0.31	1.20	0.15 0.40	0.035	0.035	---	485 620	260	21	17	2T	---

Request a Quote

Ship Buildings Steel Plates,Stainless Steel Plate Suppliers

Structural Steel Plates

We have in store for our clients, a dimensionally accurate assortment of structural steel plates that is available in several specifications which can be custom made on order. These structural steel plates are designed to meet the application specific demands of diverse industries and are offered to our clients in the following technical specifications:

Specification	Chemical Max						Mechanical MPA, min
Specification	C Max	Min Max	Si Max	S Max	P Max	Macro Alloy	Tensile Min	Yield Min	%EL 50 GL	Min 200 GL	Bend	Impact
ASTM A 36	0.26	1.2	0.15 0.40	0.05	0.04	---	400-550	250	21	18	2T	---
IS 2062
Gr - A	0.23	1.5	---	0.05	0.05	---	410	250	23	---	3T	---
B	0.22	1.5	0.4	0.045	0.045	---	410	250	23	---	2T	27 J at 0O C

Request a Quote

Stainless Steel Sheets Manufacturer,Steel Products Manufacturers

Ship Buildings Steel Plates

Our clients can avail from us, a quality assured range of ship building steel plates that is designed using steel of high tensile strength. These ship building steel plates are available in varied shapes and sizes and can also be customized for our clients on various parameters such as material of construction, weight and finish. Specifications:

Specification	Chemical Max					Mechanical MPA, min
	C Max	Min Max	Si Max	S Max	P Max	Tensile Min	Yield Min	%EL 50 GL	Impact
	C Max	Min Max	Si Max	S Max	P Max	Tensile Min	Yield Min	%EL 50 GL	0°C	-20°C	-40°C
LLOYDS / ABS / DNV Gr-A	---	2.5C Min	0.5	0.035	0.035	400 520	235	22	---	---	---
Gr-B	0.21	0.80 Min	0.35	0.035	0.035	400 520	235	22	27J(L)/20J(T)	---	---
Gr-D	0.23	0.60 1.40	0.35	0.035	0.035	400 520	235	22	---	27J(L)/20J(T)	---

Request a Quote
