the leading stockiest, importers, exporters & suppliers of Ramor 500 Plates

Ramor 500 Plates

MILITARY, ARMOR & BALLISTIC STEEL PLATE: The ballistic protection steel with high hardness

Ramor™ 500 is a ballistic protection steel of high hardness, available in thicknesses of 2 30 mm (0.079 1.18″) and hardnesses of 490 560 HBW.

Ramor 500 is available as cut-to-length sheet in thicknesses of 2 6.5 mm (0.079 0.256″) and as plate in thicknesses of 6 30 mm (0.236 1.18″). Delivered in quenched condition, Ramor 500 is not intended for further heat treatment.

Ramor 500

USED FOR DIMENSIONS STANDARDS
Armored T: 2 - 30 mm EN 10029, EN 10051

Mechanical Properties

Thickness(mm) Hardness(HBW)
2.0 - 30 490 - 560

Chemical Composition (ladle analysis)

C (max %) Si (max %) Mn (max %) P(max %) S(max %) Cr (max %) Ni (max %) Mo (max %) B (max %)
0.35 0.70 1.50 0.015 0.010 1.0 2.0 0.70 0.005

Tolerances

Thickness
Product Type Thickness(mm) Tolerance (Min / Max)
Cut Length 2.00 - 4.00 - 0.0 / + 0.36
Cut Length 4.01 - 5.00 - 0.0 / + 0.40
Cut Length 5.01 - 6.00 - 0.0 / + 0.42
Cut Length 6.01 - 6.50 - 0.0 / + 0.44
Heavy Plate 6.0 - 7.9 - 0.0 / + 0.8
Heavy Plate 8.0 - 14.9 - 0.0 / + 1.0
Heavy Plate 15.0 - 24.9 - 0.0 / + 1.2
Heavy Plate 25.5 - 30.0 - 0.0 / + 1.4

Flatness
Product Type Thickness(mm) 1000 ruler(mm)
Cut Length 2.00 - 4.00 6
Cut Length 4.01 - 5.00 6
Cut Length 5.01 - 6.00 6
Cut Length 6.01 - 6.50 6
Heavy Plate 6.0 - 7.9 6
Heavy Plate 8.0 - 14.9 6
Heavy Plate 15.0 - 24.9 6
Heavy Plate 25.5 - 30.0 6
