the leading stockiest, importers, exporters & suppliers of Hardox® 500 Plates

Hardox® 500 Plates

Hardox® 500 Plates, Abrex 500 Plate, Hardox® 500 Sheets, Abrex 500 Sheets Stockiest Exporter & Suppliers.

Abrasion Resistant Steel Plates, Hardox® 500 Sheets & Plates, Abrex 500 Plates Suppliers in Mumabi-India. )

Champak Industries engaged Stockiest, Importer, Suppliers & Exporter of wide range of Hardox® 500 ( Abrex 500 ) in Mumbai, India. These Hardox® 500 Plates is an abrasion resistant plate with a hardness of 500 HBW, intended for applications where demands are imposed on abrasion resistance in combination with good cold bending properties. These are available in various specification & thickness as per the requirements of clients. These are easily available at economical price range in the market. These steel plates are the widely used of the wear resistant grades. We make all the sizes and thickness of Hardox® 500 Plates as per the client's requirements.

Specification

Size : 5mm ~ 120 mm
Width : 1450mm to 4050mm.
Length : 3000mm to 15000mm
Thickness : 3mm to 130mm
Applications : Cutting Edges, Grizzly bars, Buffer bins, Measuring bins and Skips

Chemical Composition

Plate C Si Mn P S Cr Ni Mo B CEV CET
thickness mm max % max % max % max % max % max % max % max % max % typv typv
04/13/13 0.27 0.7 1.6 0.025 0.01 1 0.25 0.25 0.004 0.49 0.34
(13)-32 0.29 0.7 1.6 0.025 0.01 1 0.5 0.3 0.004 0.62 0.41
(32)-40 0.29 0.7 1.6 0.025 0.01 1 1 0.6 0.004 0.64 0.43
(40)-80 0.3 0.7 1.6 0.025 0.01 1.5 1.5 0.6 0.004 0.74

Mechanical Property

Grade Mechanical Property Charpy V Impact Test
HADOX® 500 HBW Thickness/Mpa Elongation Degree longitudinal
4-32MM 470-530 Min  % -40 J
(32)-80 450-540 10 40
