the leading stockiest, importers, exporters & suppliers of 7050 Aluminium Plates

7050 Aluminium Plates


Champak Industries stock 7050 ALUMINIUM PLATES, which is available in two tempers: T7451 (formerly T73651) offers better stress corrosion cracking resistance and excellent exfoliation resistance at slightly lower strength levels; and T7651 combines the highest strength with good exfoliation corrosion resistance and average stress corrosion cracking resistance.Alloy 7050 aluminum plates are the principal choice for aerospace applications, especially in the 3-6 inch thickness range. It exhibits better toughness/corrosion resistance characteristics than the older, more established alloy 7075. Since it is less quench sensitive than most other aerospace alloys, this alloy maintains its strength properties in thicker sections while retaining good stress corrosion cracking resistance and fracture toughness levels. AMS 4050 is commonly associated with 7050, though various manufacturers require their own specifications.

Applications

. Fuselage frames
. Bulkheads


Chemical Composition Limits (WT %)

Silicon 0.12
Iron 0.15
Copper 2.0-2.6
Manganese 0.1
Magnesium 1.9-2.6
Chromium 0.04
Zinc 5.7-6.7
Titanium 0.06
Others, each 0.05
Others, total 0.15
Balance, Aluminum

Typical Mechanical Properties

ThicknessTensile StrengthYield StrengthElongation
In. KSI KSI %
.250-6.00 83-73 73-63 13-11
