the leading stockiest, importers, exporters & suppliers of 5154 Aluminium Plates

5154 Aluminium Plates


Champak industries stock 5154 Aluminium Plates, which is Aluminium Alloy 5154 primary constituent is magnesium which gives this non heat treatable alloy its moderate strength. Alloy 5154 combines its strength with excellent formability and corrosion resistance and is regularly used in wire form but is now becoming popular for use with cold heading applications, specifically in solid, semi-tubular and tubular rivets. Alloy 5154 is an all-purpose alloy that meets a broad range of needs.

Chemical Composition Limits

Weight% Al Si Fe Cu Mn Cr Mg Mn +Cr Ti Zn Others Each Others Total
5154 USA Bal 0.25 max 0.40 max 0.10 max 0.10 max 0.15/0.35 3.1/3.9 - 0.20 max 0.20 max 0.05 max 0.15 max
5154 A
EWAA
Bal 0.5 max 0.5 max 0.10 max 0.50 max 0.25 max 3.10 / 3.9 0.10 / 0.50 0.20 max 0.20 max 0.05 max 0.15 max

Typical Mechanical Properties

Material Temper Wall Thickness (mm) Tensile Strength (N/mm²) Yield Strength (N/mm²) mm Elongation on 50mm
5154 Drawn tube 0 <10 215-260 85 16
5154 Drawn tube H4 <10 245 min 200 4
